Effortless Load Handling with PN FLEX Pneumatic Manipulator
The PN FLEX pneumatic manipulator is designed with a rope-type vertical arm, ideal for precise handling of loads with their center of gravity aligned along the Z-axis. Its flexible and lightweight design ensures smooth pick-and-place movements, making it perfect for tasks that demand accuracy and ease of use. Whether you're lifting, positioning, or releasing loads, PN FLEX enhances operator safety and productivity in a wide range of industrial environments.
Main Features
- Max load capacity: kg 80
- Max lift speed: 45 m/mn
- Control: pneumatic
- Air pressure: 6,0
- Noise level: < 70 dB
- Bar Work Temperatures: from +5° to +50° C
- Noise level: < 70 dB
- Main joint axis friction
- Intermediate joint axis friction
- Safety devices: in case of pressure failure slow descent till the floor
Available options
- Conformity to the ATEX Regulations for applications in controlled environments with danger of explosion: – Zone 1/2 (IIA-IIB) for gases- Zone 21/22 (IIIA-IIIB-IIIC) for dusts
- Special painting for Steel platform
- Double rope version
- Rotation blocks on the main joint
- Stainless steel version
- Pressure booster
- 3 joint arm
